Single Channel LIN RGB Slave Ambient Light Controller
MLX81112 Melexis
The MLX81112 LIN RGB slave provides a single chip IC solution for driving up to four LEDs (RGB+1) via constant current sources in automotive ambient lighting applications.
Top features
-
16-bit RISC MCU with 32kB Flash user memory +16k ROM (Driver+Libraries), RAM, EEPROM with ECC
-
Internal RC-Oscillator
-
Co-processor for MUL and DIV operations
-
LIN protocol controller according to LIN 2.x and SAE J2602
-
Low interrupt load to the application
-
LIN Transceiver according to LIN 2.x and SAE J2602
-
Support for autoconfig according bus shunt
-
4 programmable constant current/high voltage capable IOs
-
16-bit current modulation outputs
-
Interrupt capable inputs
-
10-bit ADC with integrated pre-divider connected to all IOs
-
Internal battery and reference voltage monitor
-
LED colour temperature compensation
-
Automotive temperature range of -40°C to 125°C
- SOIC8 thermally enhanced package
Single Channel LIN RGB Slave Ambient Light Controller - MLX81112
Product description
The MLX81112 LIN RGB slave provides a single chip IC solution for driving up to four LEDs (RGB+1) via constant current sources in automotive ambient lighting applications. Every output can be programmed to a maximum current of 48 mA through the built-in Flash memory.
All necessary components like physical layer LIN transceiver, LIN controller, voltage regulator and 16-bit RISC-based microcontroller, as well as supporting functions like ADC, 16-bit current modulation, constant current high voltage capable outputs and LED color temperature compensation are integrated into the chip.
It also includes the possibility for LIN auto-configuration and can thus be used for other applications requiring a low pin count fully integrated LIN slave. The LIN protocol handler meets all LIN standards including LIN2.x, as well as SAE J2602.
To support a high thermal performance by keeping the low cost target, our MLX81112 is offered in a thermally enhanced SOIC8 package.
Features and benefits
-
16-bit RISC MCU with 32kB Flash user memory +16k ROM (Driver+Libraries), RAM, EEPROM with ECC
-
Internal RC-Oscillator
-
Co-processor for MUL and DIV operations
-
LIN protocol controller according to LIN 2.x and SAE J2602
-
Low interrupt load to the application
-
LIN Transceiver according to LIN 2.x and SAE J2602
-
Support for autoconfig according bus shunt
-
4 programmable constant current/high voltage capable IOs
-
16-bit current modulation outputs
-
Interrupt capable inputs
-
10-bit ADC with integrated pre-divider connected to all IOs
-
Internal battery and reference voltage monitor
-
LED colour temperature compensation
-
Automotive temperature range of -40°C to 125°C
- SOIC8 thermally enhanced package
